YSD 271 & 289
YSD gate configurations designed for reliable flow control and long-term operational efficiency.
YSD 271 & 289 Outlet Gate Replacement Parts
Click on gate part number to view more detail
| Number | Description | Part Number |
| 1 | Plastic Outlet Cap (271D) | YSDG-73883 |
| 1 | Plastic Outlet Cap (271J/K/M, 289 series) | YSDG-73670 |
| 2 | Outlet Nozzle Gasket | EAG271DE |
| 3 | Swing Bolt (eye-nut side) | YSD4SB |
| 4 | Eye Nut (all) | YSD2EN |
| 5 | Compression Knob (all) | YSD134CK |
| 6 | Eyebolt (compression side) | YSD358SB |
| 7 | Clevis Pin (271J/K/M, 289 series) | YSD334CP |
| 7 | Celvis Pin (271D) | YSD225CP |
| 8 | Clevis Pin (289 series) | YSD134CP |
| 9 | Valve Seal Assembly | YSDZG70333 |
| 10 | Handle | YSDZG64135 |
| 11 | End Adapter Gasket | EA289EAG26 |
| 12 | End Adapter Casting (Anodized) | WHMKE10496 |
| Number | Description | Part Number |
| *13 | Mounting Gasket (289 series) | GGTR35 / GGTR3125 |
| *14 | Mounting Gasket (271 series) | GG35 / GGTR111 |
| *15 | Roll Pin (All) | T532RP |
| *16 | End Adapter Valve Access (271D | YSD271G |
| *17 | Plastic Rivet For Cap Gasket Fastener | YSDG79164 |
| *18 | Handle Grip | YSDG79836 |
| *19 | End Adapter (Bolt On) | YSDZG64166 |
| *20 | Control Valve (271 J,K,M) | YSDG65896 |
| *21 | Control Valve (289 A,B) | YSDG70708 |
| *22 | Center Valve For YSD 271 | WHMKE10479 |
| *23 | Valve Indicator Label | YSDG73933 |
| *24 | End Adapter Casting (Non-Anodized) | YSDZG70716 |
| *25 | Mounting Bolt Kit (32 Bolt Hole)(½”-13” x 2 ¼”) | MBKA225 |
| *26 | Mounting Bolt Kit (38 Bolt Hole)(½”-13” x 2 ¼”) | MBKA225T |
| * Items Not Shown On Drawing |
